KYCM24G series intelligent miniature circuit breakers have the characteristics of advanced and reasonable structure, reliable performance, high breaking capacity, and beautiful appearance. The shell material is composed of high-quality impact-resistant and high-flame retardant materials. It is suitable for indoor, AC 50Hz, rated voltage 230V, three-phase 400V, and rated current not exceeding 100A. It is mainly used for low-voltage terminal power distribution in industrial, commercial, civil buildings and infrastructure in buildings and similar places. Leakage, overload, short circuit, over-under-voltage, over-heating, and lack of equal protection can also be used for infrequent on-off operations. The leakage circuit breaker with the rated residual operating current less than 30mA can provide protection for personal electric shock.
| Number of poles | 1P, 2P, 3P, 4P |
| Breaking capacity | 1A-63A, 10kA |
| 80-100A, 6kA | |
| Rated voltage | 230/400V AC |
| Rated current | 1A-100A |
| Residual current type | A type, AC type |
| Residual current specifications | 30, 100, 300mA or adjustable |
| Trip time | Standard type, time delay type, adjustable type |
| Configurable leakage function | Shut down, alarm, alarm and protection |
| Leakage self-test | Automatic non-trip self-check, remote and local trip self-check |
| Short circuit protection | Type B, Type C, Type D |
| Trip time | ＜0.1s |
| Overcurrent protection | Thermal element + electronic |
| Thermal trip | Inverse time limit |
| Electronic trip | Inverse time or definite time |
| Working current | Electronically adjustable |
| Overvoltage protection | JB/T 12762 OUPA standard |
| Overvoltage setting value | 275V |
| Undervoltage setting value | 0.7Ue |
| Action time | Standards compliant |
| Meet the standard | Shut down, alarm, alarm and protection |
| Terminal temperature rise protection | Alarm + protection |
| Temperature rise alarm setting value | ＞50K |
| Temperature rise action setting value | ＞60K |
| Action time | 15min |
| Temperature rise protection function can be configured | Shut down, alarm, alarm and protection |
| Three-phase unbalance | Monitoring + alarm |
| Lack of phase | Monitoring + alarm + protection |
| Configurable function | Shut down, alarm, alarm and protection |
series intelligent miniature circuit breakers have the characteristics of advanced and reasonable structure, reliable performance, high breaking capacity, and beautiful appearance. The shell material is composed of high-quality impact-resistant and high-flame retardant materials. It is suitable for indoor, AC 50Hz, rated voltage 230V, three-phase 400V, and rated current not exceeding 100A. It is mainly used for low-voltage terminal power distribution in industrial, commercial, civil buildings and infrastructure in buildings and similar places. Leakage, overload, short circuit, over-under-voltage, over-heating, and lack of equal protection can also be used for infrequent on-off operations. The leakage circuit breaker with the rated residual operating current less than 30mA can provide protection for personal electric shock.
| Number of poles | 1P, 2P, 3P, 4P |
| Breaking capacity | 1A-63A, 10kA |
| 80-100A, 6kA | |
| Rated voltage | 230/400V AC |
| Rated current | 1A-100A |
| Residual current type | A type, AC type |
| Residual current specifications | 30, 100, 300mA or adjustable |
| Trip time | Standard type, time delay type, adjustable type |
| Configurable leakage function | Shut down, alarm, alarm and protection |
| Leakage self-test | Automatic non-trip self-check, remote and local trip self-check |
| Short circuit protection | Type B, Type C, Type D |
| Trip time | ＜0.1s |
| Overcurrent protection | Thermal element + electronic |
| Thermal trip | Inverse time limit |
| Electronic trip | Inverse time or definite time |
| Working current | Electronically adjustable |
| Overvoltage protection | JB/T 12762 OUPA standard |
| Overvoltage setting value | 275V |
| Undervoltage setting value | 0.7Ue |
| Action time | Standards compliant |
| Meet the standard | Shut down, alarm, alarm and protection |
| Terminal temperature rise protection | Alarm + protection |
| Temperature rise alarm setting value | ＞50K |
| Temperature rise action setting value | ＞60K |
| Action time | 15min |
| Temperature rise protection function can be configured | Shut down, alarm, alarm and protection |
| Three-phase unbalance | Monitoring + alarm |
| Lack of phase | Monitoring + alarm + protection |
| Configurable function | Shut down, alarm, alarm and protection |
