| ELECTRICAL PERFORMANCE | |
| Rated current | 16A/32A |
| Operation voltage | 250V |
| Insulation resistance | ＞500MΩ(DC500V） |
| Contact Resistance | 0.5mΩ Max |
| Terminal temperature rise | ＜50K |
| Withstand voltage | 1500V |
| MECHANICAL PROPERTIES | |
| Mechanical life | no-load plug in/out ＞10000 times |
| Coupled insertion force | 45N＜F＜100N |
| Impat of external force | can afford 1M drop |
| ENVIRONMENTAL PERFORMANCE | |
| Operating temperature | -30℃-﹢50℃ |
| APPLIED MATERALS | |
| Case material | thermoplastic,flame retardant grade UL94 V-0 |
| Terminal | Copper alloy,silver plating |
| CONTROL BOX FUNCTION | Leakage protection |
| Overvoltage under-voltage protection | |
| Over load protection | |
| Lightningprotection | |
| Ground protection | |
| Over-temperature protection | |
