| ELECTRICAL PERFORMANCE | |
| Rated current | 16A/32A |
| Operation voltage | 250V/480V |
| Insulation resistance | ＞500MΩ(DC500V） |
| Contact Resistance | 0.5mΩ Max |
| Terminal temperature rise | ＜50K |
| Withstand voltage | 2000V |
| MECHANICAL PROPERTIES | |
| Mechanical life | no-load plug in/out ＞10000 times |
| Coupled insertion force | 45N＜F＜100N |
| Impat of external force | can afford 1M drop |
| ENVIRONMENTAL PERFORMANCE | |
| Operating temperature | -30℃-﹢50℃ |
| APPLIED MATERALS | |
| Case material | thermoplastic,flame retardant grade UL94 V-0 |
| Terminal | Copper alloy,silver plating |
| Rared current | Cable specification | Remarks |
| 16A Single phase | 3X2.5MM²+1X0.75MM²TPU,Φ10.5/TPE,Φ13.5 | Shell color: black/white optional Cable color: black/orange/green optional |
| 16A Single phase | 5X2.5MM²+1X0.75MM²TPU,Φ13/TPE,Φ16.3 | |
| 32A/40A Single phase | 3X6MM²+1X0.75MM²TPU,Φ13/TPE,Φ16.3 | |
| 32A/40A Single phase | 5X6MM²+1X0.75MM²TPU,Φ16.3 |
