| ELECTRICAL PERFORMANCE | |
| Rated current | 80A/125A/160A/200A |
| Operation voltage | 1000V |
| Insulation resistance | ＞500MΩ(DC500V） |
| Contact Resistance | 0.5mΩ Max |
| Terminal temperature rise | ＜50K |
| Withstand voltage | 3000V |
| MECHANICAL PROPERTIES | |
| Mechanical life | no-load plug in/out ＞10000 times |
| Coupled insertion force | 45N＜F＜100N |
| Impat of external force | can afford 1M drop |
| ENVIRONMENTAL PERFORMANCE | |
| Operating temperature | -30℃-﹢50℃ |
| APPLIED MATERALS | |
| Case material | thermoplastic,flame retardant grade UL94 V-0 |
| Terminal | Copper alloy,silver plating |
| Rated current | Cable specification | Remarks |
| 63A/80A | 2X16MM²+16MM²+3X2X0.75MM²TPU,Φ26/TPE,Φ32 | Shell color: white Cable color: black |
| 125A | 2X35MM²+25MM²+3X2X0.75MM²TPU,Φ31.5/TPE,Φ34 | |
| 160A | 2X50MM²+25MM²+3X2X0.75MM²TPU,Φ34.5/TPE,Φ37 | |
| 200A | 2X70MM²+25MM²+3X2X0.75MM²TPU,Φ37/TPE,Φ40 |
